When the man-machine interface is installed to the fixed panel to provide dust proof and moisture proof function. (1)GP3000H portable slingUsed to connect to an external device (Type-A RS-422/RS-485 interface) to an external device (USB interface)."Screen size: 10.4 inches.
Power supply voltage: AC220V.
Display type: TFT color LCD.
Resolution: 640 x 480 pixels.
Display color: 256 color.
Internal memory: FEPROM 4MB PFXZCBFN50
Backup memory: SRAM 256KB.
Interface: CF card, Ethernet, serial port expansion, video function (optional).
High definition picture resolution function menu for beginners to learn programming design.
The parts list and edit images are in the same window,
So you can use a simple drag and drop action,
Pull the parts into the edit screen to quickly and easily configure the components you need.
Move the mouse to the appropriate parts of the image, there will be a description of the operation of the parts,
Help you make the edit screen.
GP2000 advanced technology.
Touch screen operation.
Online multi language switch.
Windows font input.
256 color display.
4 channel video screen display, 1 RGB input, 1 RGB output.
Bar chart, scale chart, pie chart and trend chart.
Active window.
Support the Eurasian font.
Backlight lamp fault detection function.
RISC CPU 100MHz.
JPEG image uptake.
Transmission of JPEG format files through the network.
SRAM data backup.
The use of CF production data exchange.
ADO/DDE/DLL/OPC/SQL instant data collection (Pro-Server).
"" "GP-Web" through the Internet / Intranet for remote monitoring.
The CF card maintenance screen data.
Maintain screen data through ethernet.
Data record.
Formula function.
Alarm message history. "Analog /NPN output type.
Display size: 5.7 inches.
Resolution: 320 x 240 pixels (QVGA).
LCD:TFT.
Color: 65536 color.
Ethernet interface: 1.
Serial port: 1.
CANopen interface: 1.
USB (host):1.
USB (equipment):1.
Built in DIO input: 12 points.
Built in DIO output: 6 points.
Built in AIO input: 4 points.
Built in AIO output: 2 points.
Common DIO:2 point high speed counter (with synchronous output) pulse capture input.
Dedicated DIO:2 point pulse output, PWM output.
Expansion module EX module: none.
Expansion module CANopen module: 63 stations.
Controller memory size: EPROM 132KB FLASH (equivalent to 15000 steps (up to 60000 steps).
CANopen network
LT4000M supports data exchange with a variety of remote devices through the CANopen, easy to achieve economic and easy to use system design.
Can choose standard I/O module, also can choose action or control module and other more advanced products in complex application.
Flexible installation.
The control module can be installed on the DIN guide rail by using the split installation cable,
And the display module is installed in other locations.
Display module occupies a small space, even if the space is limited, but also can be flexible to install.
Compact size.
The volume is small but the display is fresh and bright, can create a rich and readable operation picture.
The control function of the whole and the digital I/O, analog I/O, analog temperature input and USB, serial port and Ethernet communication interface.
Integrated design.
Adopt integrative design, compact structure,
When the installation is only required to open a hole in the panel 22mm.
The display module or the control module can be easily replaced when the fault is eliminated.
PFXZCBFN50 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=PFXZCBFN50&select=5
