Input voltage: DC24V.
Screen size: 5.7 inches.
Display type (resolution):65536 color TFT display LCD (QVGA 320 x 240 pixels).
Touch panel type: analog resistance.
Memory: 16MB (internal memory), SRAM320KB (backup memory), SRAM64KB (variable area).
Ethernet interface: 1.
Serial port: RS-232C * 1, RS-422/485 * 1.
SD card slot (max 32GB):1.
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1.
Replaceable battery: yes PS-BH00
Alarm analysis function block: yes.
Panel opening size:
Wide 118.5 x high 92.5mm (+1/0mm).
Panel thickness: 1.6-5mm, chamfer radius is less than R3.
Simplify troubleshooting.
Using alarm analysis function, can grasp the cause of the fault in time.
Just a few clicks, you can set the alarm analysis screen,
Analysis of the status data of the register related to the alarm.
Remote monitoring and control.
Using remote monitoring software EX GP-Viewer,
Can be from a running PC system Windows remote monitoring of the production scene of the man-machine interface screen. Transmission screen data, such as the USB cable, PC (Type-A USB) to the man-machine interface USB (Type-A)Fitting on NETWORK FLEX interface. Connecting NETWORK FLEX communication cable. (5 / set)To prevent the connection of disconnected USB cable fastening clips (Mini-B USB, 1 interface, 5 / set)Output points: 1 points.
Rated output voltage range: voltage output: 0 to 10V, current input: 4 to 20mA.
Resolution: 12. Screen size: 5.7 inches.
Display type: STN pseudo color LCD.
Resolution: 320 x 240 pixels.
Display color: 64 color.
Internal memory: FEPROM 2MB.
Backup memory: SRAM 256KB.
Interface: CF card, Ethernet, serial port expansion.
Touch input unit, start input mode.
Increase the number of times, the cumulative time and alarm level message.
Alarm sort function (according to the date, the number of times, etc.).
Increase in the number of clocks, from the previous 3 to 8.
Different colors represent different levels of information.
Multiple input items, can be specified in the input sequence function (also can specify the group).
When the individual setting parameters are changed, the notification bit can be set.
Automatically bounce the keyboard position, can be more flexible settings.
High definition picture resolution function menu for beginners to learn programming design.
The parts list and edit images are in the same window,
So you can use a simple drag and drop action,
Pull the parts into the edit screen to quickly and easily configure the components you need.
Move the mouse to the appropriate parts of the image, there will be a description of the operation of the parts,
Help you make the edit screen.
Using Tags can make the picture editing more flexible.
Up to 3 windows can be displayed at the same time (in which 2 Tag U window).
Display history alarm data.
Touch panel operation is easier to set.
In the programmable man-machine interface screen can display the Windows font you need into image data.
Now you can increase the font in the general conversion coefficient of 8, 2, 4 and 1,
And zoom in between 1 and 8.
This allows you to precisely adjust the font size to suit your layout.
Simple arrangement of components and markers to select 1200 of the available styles can be quickly and easily create the screen.
PS-BH00 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=PS-BH00&select=5
