B/B+/C FLEX NETWORK Type connector (5)Converting 2 analog signals into digital signals12.1 inches, replace the backlight (1 / set)Connector for connecting a serial port (1)Output points: 1 points.
Rated output voltage range: voltage output: 0 to 10V, current input: 4 to 20mA.
Resolution: 12. Interface module for the simultaneous use of A/QnA/FX series external controllerTouch panel operation for RGB input modules (Master - from: Mini-B)For 5 GP570-WP10-MS7 inch models, for fixing the hooks of the three EX modules.Controller DIO (PNP model):6 point type NPN input, 2 point NPN type output, connector: 12 pin.
Specification: DC24/C (control) level models.
Display type: monochrome LCD.
Display size: 10.4 inches.
Resolution: 640 x 480 pixels (VGA).
Display color: monochrome (16 gray level).
Backlight: cold cathode lamp (backlight lamp replacement: return to repair).
Brightness adjustment: 8 level adjustment can be carried out by touch panel.
Variable area: 64KB SRAM (using lithium battery).
Program area: EPROM 132KB FLASH.
Step number: equivalent to 15000 steps.
Touch panel type: resistance type (analog).
Easily upgrade.
GP/ST series supports GP series of all models of the screen data, including the first generation of the GP10 series.
GP product family to maintain the size of the opening of the panel compatibility, to facilitate easy replacement.
Simulated running status on PC.
Use PC simulation function, do not need to transfer the picture to GP,
You can check all the functions of GP on the PC - including the screen operation, D script, logical script.
Record machine status to diagnose error causes.
GP3000 series of M (Multimedia) level models of the event recording function can be recorded in the operation of the device,
This will help save and analyze the error log.
Rich sample images can reduce programming time.
Pro-face provides a large number of sample images and 3D parts,
So you can easily create a beautiful and intuitive picture, in order to save editing time.
Can improve the efficiency of the 5 functions.
Using EX GP-Pro can easily create a clear picture and save the creation time.
Screen and logic programming software EX GP-Pro interface is very friendly,
The drag and drop feature makes the software interface easy to operate.
EX GP-Pro powerful features, such as 3D simulation components, image fonts and simulation functions,
Even beginners can easily and quickly grasp how to create a picture.
GP570-WP10-MS Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=GP570-WP10-MS&select=5
