GLC2500-TC41-200V Interface
Proface GLC2500-TC41-200V Manual And Instructions
GLC2500-TC41-200V User's Manual

Proface GLC2500-TC41-200V Product information and technical parameters:
Brand: Proface
Name: Interface
Model: GLC2500-TC41-200V
Screen size: 10.4 inches.
Display type: TFT color LCD.
Display color: 256 color (no flash) /64 color (3 speed flicker).
Backlight: CCFL (service life: more than 50000 hours, 24 hours of continuous work).
Resolution: 640 x 480 pixels.
Brightness control: 4 level adjustment can be carried out by touch panel.
Voltage: AC220V.
Internal memory: FLASH EPROM 4MB.
Backup memory: 256KB SRAM.
Interface: Ethernet, CF card.

Controller DIO (PNP model):6 point type NPN input, 2 point NPN type output, connector: 12 pin.
Specification: DC24/C (control) level models.
Display type: monochrome LCD.
Display size: 10.4 inches.
Resolution: 640 x 480 pixels (VGA).
Display color: monochrome (16 gray level).
Backlight: cold cathode lamp (backlight lamp replacement: return to repair) GLC2500-TC41-200V.
Brightness adjustment: 8 level adjustment can be carried out by touch panel GLC2500-TC41-200V
Variable area: 64KB SRAM (using lithium battery).
Program area: EPROM 132KB FLASH.
Step number: equivalent to 15000 steps.
Touch panel type: resistance type (analog).
Easily upgrade.
GP/ST series supports GP series of all models of the screen data, including the first generation of the GP10 series GLC2500-TC41-200V.
GP product family to maintain the size of the opening of the panel compatibility, to facilitate easy replacement.
Simulated running status on PC.
Use PC simulation function, do not need to transfer the picture to GP,
You can check all the functions of GP on the PC - including the screen operation, D script, logical script.
Record machine status to diagnose error causes GLC2500-TC41-200V.
GP3000 series of M (Multimedia) level models of the event recording function can be recorded in the operation of the device,
This will help save and analyze the error log.
Rich sample images can reduce programming time.
Pro-face provides a large number of sample images and 3D parts,
So you can easily create a beautiful and intuitive picture, in order to save editing time.
Can improve the efficiency of the 5 functions.
Using EX GP-Pro can easily create a clear picture and save the creation time.
Screen and logic programming software EX GP-Pro interface is very friendly,
The drag and drop feature makes the software interface easy to operate.
EX GP-Pro powerful features, such as 3D simulation components, image fonts and simmulation functions,
Even beginners can easily and quickly grasp how to create a picture GLC2500-TC41-200V. Display size: 5.7 inches.
Display type: monochrome LCD.
Display color: blue and white.
Resolution: 320 x 240 pixels.
Input voltage: DC24V.
Conntrol memory: EPROM 1MB FLASH GLC2500-TC41-200V.
Program area: 128KB.
Variable area: 32KB.
Interface: built-in DIO 32 points (16 point input /16 point output, PNP type).
