Output point: 8 point transistor (PNP).
Rated output voltage: DC24V.
External connection: 10 pin terminal connector.
Public end design: 8 point /1 public end. Touch screen anti ultraviolet protective film (1 pieces).The main controller is connected to the host computer interface (can be switched between RS-232C and RS-422) using the isolation module.Input voltage: DC24V.
Screen size: 7 inch widescreen PFXZCFWG32
Display type (resolution):65536 color TFT (WVGA 800 x 480 pixels).
Touch panel type: analog resistance.
Memory: 16MB (internal memory), SRAM128KB (backup memory).
Ethernet interface: 1.
Serial port: RS-232C * 1, RS-422/485 * 1.
SD card slot (max 32GB):1.
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1.
Replaceable battery: yes.
Alarm analysis function block: No.
Panel opening size:
Wide 204.5 x high 159.5mm (+1/0mm).
Panel thickness: 1.6-5mm, chamfer radius is less than R3.
Coating models: none.
Easily connect a variety of USB devices
Can be easily connected to the man-machine interface serial controller, EZ series accessories, bar code reader and USB memory.
Remote data acquisition and management
Human machine interface, which is installed on the production machine,
With EX Microsoft software combined with Office Pro-Server and SQL and other standard PC software,
Can be simple and economical to establish a set of data management system, and effectively improve the quality of production and efficiency. 3.5 inch screen protective cover (1 pieces)The main controller is connected to the man-machine interface for MPI communicationFor connecting GP operation data with RS-422 and power /DIO terminals.10.4 inches and above, used to connect the power cord (5 / set).Used to install the GP3000H series to a commercially available support arm or panel."Size: 10.4 inches.
Display type: TFT color LCD.
Resolution: 640 x 480 pixels (VGA).
Display color: 256 color (no flash) /64 color (3 speed flicker).
Power supply: DC24V.
Interface: USB (TYPE-A), RS-232C, RS-422/485 (MPI).
Brightness adjustment: 8 level adjustment can be carried out by touch panel.
Using the alarm log to quickly check and display the alarm message and register value, it is easier to find the cause of the fault.
Register value will be recorded when the alarm is issued.
Therefore, the state of the register and its value can be obtained while acquiring the alarm message.
A comparison of the data is helpful to find the cause of the fault.
These "sample parts" can be used directly, and the design time is greatly reduced.
According to ID number of easy access to the operation log, through the analysis of the operation to improve production efficiency.
Use ID based on the number of authorized mode of operation, can be recorded when, who performed the operation.
Using this data, you can analyze the causes of all the faults that have occurred.
You can easily and intuitively set the address by dragging and dropping the mouse.
In addition, click on the use of the address can be displayed on the screen number and part number.
Click the part number to jump to the screen using the widget.
The same software supports all 3000 series of Pro-face man-machine interface.
From the screen to create the programming, the functions are simple and easy to use.
Learn a software, master all the skills.
Support efficient image creation.
ID management and operation log reduces downtime.
Improve the operation mode, reduce the cost and workload.
Analysis of failure causes according to the operation log.
Check register status on historical trend chart.
Drag and drop functionality makes the software interface easier to operate.
A variety of components to provide a variety of components, easy to create a beautiful picture.
In addition, there are a variety of 256 color components can be used. "
PFXZCFWG32 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=PFXZCFWG32&select=5
