Screen size: 7.4 inches.
Display type: TFT color LCD.
Display color: 256 color (no flash) /64 color (3 speed flicker).
Backlight: CCFL (service life: more than 50000 hours, 24 hours of continuous work).
Resolution: 640 x 480 pixels.
Brightness control: 4 level adjustment can be carried out by touch panel.
Voltage: DC24V.
Internal memory: FLASH EPROM 4MB.
Backup memory: 256KB SRAM.
Interface: Ethernet, CF card PFXZCBADTM1 Used to output the image signal from the host computer to GPTouch screen anti ultraviolet protective film (1 pieces).Display size: 3.8 inches.
Display type: monochrome LCD.
Display color: black and white (2 gray level) / black and white (8 gray level).
Backlight: LED backlight.
Resolution: 320 x 240 pixels.
Brightness control: 2 level adjustment can be carried out by touch panel.
Contrast control: 8 level adjustment can be carried out through the touch panel.
Memory: EPROM 640KB FLASH.
Serial port: RS-232C/422.
Ethernet port: 10BASE-T. Input voltage: DC24V.
Screen size: 5.7 inches.
Display type (resolution):65536 color TFT (QVGA 320 x 240 pixels).
Touch panel type: analog resistance.
Memory: 8MB (internal memory), SRAM128KB (backup memory).
Ethernet interface: 1.
Serial port: RS-232C * 1, RS-422/485 * 1.
SD card slot (max 32GB):1.
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1.
Replaceable battery: no (rechargeable battery).
Alarm analysis function block: No.
Panel opening size:
Wide 156 x high 123.5mm (+1/0mm).
Panel thickness: 1.6-5mm, chamfer radius is less than R3.
Coating models: none.
Easily connect a variety of USB devices
Can be easily connected to the man-machine interface serial controller, EZ series accessories, bar code reader and USB memory.
Remote data acquisition and management
Human machine interface, which is installed on the production machine,
With EX Microsoft software combined with Office Pro-Server and SQL and other standard PC software,
Can be simple and economical to establish a set of data management system, and effectively improve the quality of production and efficiency.
