Video-Mix module (32000 color, video input x 4 channel, analog RGB input x 1 channel, analog RGB output x 1 channel, VGA/SVGA)SP-5500WA+SP-5B40 combination.
Screen size: 7 inch widescreen (WXGA).
Multi touch: support.
Windows applications - -.
Application storage space: 64MB (CFast card).
Video / audio: support.
CFast card: 2.
SD card: 1.
USB interface Type-A:3.
USB interface Mini-B:1.
Serial port: 2 PFXSP5B10
Ethernet port: 2.
Rated voltage: DC24V.
SP-5500WA+SP-5B10 combination.
Screen size: 7 inch widescreen (WXGA).
Multi touch: -.
Windows applications - -.
Application storage space: 64MB (SD card).
Video / audio: -.
CFast card: -.
SD card: 2.
USB interface Type-A:2.
USB interface Mini-B:1.
Serial port: 2.
Ethernet port: 2.
Rated voltage: DC24V.
The widescreen display can display more information.
Through the network segment, the intelligent man-machine interface can connect the factory and the office under the premise of ensuring high security.
The diversity of overseas production and market demand is increasing, and the establishment and maintenance of the machine can be completed efficiently.Output point: 16 point transistor (NPN).
Rated output voltage: DC24V.
External connection: MIL connector.
Public end design: 16 point /1 public end. Connector for connecting DC power cord. (linear, 5 / set)Used to prevent disconnection. (1 interface, 5 / set)Input voltage: AC100~240V.
Screen size: 12.1 inches.
Display type (resolution):65536 color TFT display LCD (SVGA 800 x 600 pixels).
Touch panel type: analog resistance.
Memory: 32MB (internal memory), SRAM320KB (backup memory), SRAM64KB (variable area).
Ethernet interface: 1.
Serial port: RS-232C * 1, RS-422/485 * 1.
SD card slot (max 32GB):1.
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1.
Replaceable battery: yes.
Alarm analysis function block: yes.
Panel opening size:
Wide 301.5 x high 227.5mm (+1/0mm).
Panel thickness: 1.6-5mm, chamfer radius is less than R3.
Coating models: there.
Enhance the display effect.
All models are using 65535 color LCD TFT, and has the high brightness control function of the backlight.
Exquisite picture not only improves the quality of monitoring, but also increases the safety of operation.
Mobile terminal remote monitoring.
With light and portable iPhone, iPad, touch iPod and other mobile terminal remote monitoring of large or long distance applications, large-scale processing system or production site of a number of machines.
PFXSP5B10 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=PFXSP5B10&select=5
