Display size: 3.4 inches.
Display color: STN monochrome LCD16 gray level.
Resolution: 200 x 80 pixels.
Backlight: White / Pink / red.
Touch screen type: resistance type (analog).
Storage space: 2.2MB.
Interface: RS-232C.
Rated voltage: DC24V.
Backlight color scheme and interface type!
Two groups of 3 color backlight and serial port or Ethernet interface combination, a total of 8 models to choose from PFXGP4201TAD
Horizontal or vertical installation options!
GP4100 can be installed horizontally or vertically, and can be used flexibly in many occasions.
Resolution of 200 x 80 pixels, small characters can be clearly displayed, so that the picture editing more flexible.
Image font support multi language features, can clearly and beautifully display a variety of languages.
You can display messages in an image font so that it is easy to read.
With bitmap fonts and image fonts can make the figures show more clearly.
The use of 16 gray level components, you can create a clear and easy to operate the screen.
Provide a variety of graphics for screen design selection, so that the running state at a glance.
Using 16 gray, can clearly show the JPEG and BMP images.
Can create a unique start screen. 5.7 inch screen protective cover (1 pieces)Portable GP2000H series models accessories, RS-422 cable with D-Sub connector (10 meters).SP-5600WA+SP-5B40 combination.
Screen size: 12 inch widescreen (WXGA).
Multi touch: support.
Windows applications - -.
Application storage space: 64MB (CFast card).
Video / audio: support.
CFast card: 2.
SD card: 1.
USB interface Type-A:3.
USB interface Mini-B:1.
Serial port: 2.
Ethernet port: 2.
Rated voltage: DC24V.
SP-5600WA+SP-5B10 combination.
Screen size: 12 inch widescreen (WXGA).
Multi touch: -.
Windows applications - -.
Application storage space: 64MB (SD card).
Video / audio: -.
CFast card: -.
SD card: 2.
USB interface Type-A:2.
USB interface Mini-B:1.
Serial port: 2.
Ethernet port: 2.
Rated voltage: DC24V.
The intelligent man machine interface of the two Ethernet interface can be assigned a different IP address.
In this way, we can establish a network of high security between the office and the factory.
In addition, the collected data can be saved to NVRAM to avoid data loss.
Display module and host module free combination, function and size of flexible
6 Display Module 2 host module, can realize the 12 kinds of "intelligent man-machine interface".
Modular design, display module and the host module can be split, so that can be replaced.
PFXGP4201TAD Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=PFXGP4201TAD&select=5
