"Size: 5.7 inches.
Display type: STN pseudo color LCD.
Resolution: 320 x 240 pixels (QVGA).
Display color: 256 color (no flicker) /64 color (flashing).
Power supply: DC24V.
Interface: USB (host), RS-232C, RS-422/485.
Backlight: cold cathode fluorescent lamp replacement: return to repair.
Brightness adjustment: 8 level adjustment can be carried out by touch panel.
Learn a software, master all the skills GP37W2-DF00
Support efficient image creation.
ID management and operation log reduces downtime.
Improve the operation mode, reduce the cost and workload.
Analysis of failure causes according to the operation log.
Check register status on historical trend chart.
Drag and drop functionality makes the software interface easier to operate.
A variety of components to provide a variety of components, easy to create a beautiful picture.
In addition, there are a variety of 256 color components can be used.
These "sample parts" can be used directly, and the design time is greatly reduced.
According to ID number of easy access to the operation log, through the analysis of the operation to improve production efficiency.
Use ID based on the number of authorized mode of operation, can be recorded when, who performed the operation.
Using this data, you can analyze the causes of all the faults that have occurred.
You can easily and intuitively set the address by dragging and dropping the mouse.
In addition, click on the use of the address can be displayed on the screen number and part number.
Click the part number to jump to the screen using the widget.
The same software supports all 3000 series of Pro-face man-machine interface.
From the screen to create the programming, the functions are simple and easy to use. "Colorful LED switch with USB interface.Controller DIO (NPN model):6 point type NPN input, 2 point NPN type output, connector: 12 pin.
Specification: DC24/C (control) level models.
Display type: TFT color LCD.
Display size: 5.7 inches.
Resolution: 320 x 240 pixels (QVGA).
Display color: 65536 color (no flicker) /16384 color (flashing).
Brightness adjustment: cold cathode lamp (backlight lamp replacement: return to repair).
Touch panel type: resistance type (analog).
Remote operation and monitoring in the Office
In the office or other remote side can monitor the production site of the GP screen.
Without picture editing or programming, you can achieve real-time management and monitoring, and now, you can also provide more efficient remote maintenance control.
Rich sample images can reduce programming time.
Pro-face provides a large number of sample images and 3D parts,
So you can easily create a beautiful and intuitive picture, in order to save editing time.
Easily upgrade.
GP/ST series supports GP series of all models of the screen data, including the first generation of the GP10 series.
GP product family to maintain the size of the opening of the panel compatibility, to facilitate easy replacement.
No need to open the control panel, through the PLC to monitor the GP program.
Through the data through the GP function, you can easily debug the ladder program and adjust the data due to changes in the production line by GP easily.
Error visualization.
The controller is directly connected to the GP, and the key error information of the controller can be displayed on the GP by using the sample unit.
Simulated running status on PC.
Use PC simulation function, do not need to transfer the picture to GP,
You can check all the functions of GP on the PC - including the screen operation, D script, logical script.
Providing operation and maintenance instructions through video mode, which can save maintenance cost.
The operation and maintenance instructions provided by the video mode can make any operator easy to master the operation method.
Data transmission using USB memory.
In the production site using USB memory can be easily transferred to the production line change and change the screen data.
Can improve the efficiency of the 5 functions.
Using EX GP-Pro can easily create a clear picture and save the creation time.
Screen and logic programming software EX GP-Pro interface is very friendly,
The drag and drop feature makes the software interface easy to operate.
EX GP-Pro powerful features, such as 3D simulation components, image fonts and simulation functions,
Even beginners can easily and quickly grasp how to create a picture.
GP37W2-DF00 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=GP37W2-DF00&select=5
