Slave station module for connecting support for CANopenDisposable film (5 sheets / sets) for protecting screen against contamination of human computer interface.Data transmission cable between host and LT series. Length: 5 meters.Suitable for GLC2300 seriesTouch screen anti ultraviolet protective film (1 pieces).Display size: 4.3 inches.
Display color: TFT color LCD.
Resolution: 480 x 272 pixels (WVGA) GP3000-EXDM01
Display color number: 65536 color.
Backlight: LED.
Touch screen type: analog.
Storage space: 8MB.
Interface: RS-232C.
Rated voltage: DC12-DC24V.
Compact body, powerful and easy to use.
Easy customization.
Picture editing software support multi language.
Easy data processing.
Using USB (A Type) interface or Ethernet interface, easy to place the data.
Meet the development needs of the Internet era of industrial development needs of the data processing functions.
In the era of Internet of things, the demand for information on the spot is also increasing.
Configuring the GP4100 series of Ethernet and USB interfaces, even if it''s small and compact, allows you to easily access all kinds of information (such as alarms, recipes, and samples).
Improved visualization and operability of small size human computer interface.
Resolution of 480 x 272 pixels, in a limited range of visibility can also clearly show the information.
The 65536 color display effect greatly improves the visualization and avoids the error operation caused by the low quality display of the monochromatic model. LT4000M (module type DIO), NPN output, DC24V (host).Specifications: DC24/H (handheld) class models.
Emergency stop switch: Red / key switch.
Display type: STN pseudo color LCD.
Display size: 5.7 inches.
Resolution: 320 x 240 pixels (QVGA).
Display color: 4096 color.
Backlight: white LED (back light lamp replacement: return to repair).
Brightness adjustment: 16 level adjustment can be carried out by touch panel.
Touch panel type: resistance type (analog).
Can improve the efficiency of the 5 functions.
Using EX GP-Pro can easily create a clear picture and save the creation time.
Screen and logic programming software EX GP-Pro interface is very friendly,
The drag and drop feature makes the software interface easy to operate.
EX GP-Pro powerful features, such as 3D simulation components, image fonts and simulation functions,
Even beginners can easily and quickly grasp how to create a picture.
Providing operation and maintenance instructions through video mode, which can save maintenance cost.
The operation and maintenance instructions provided by the video mode can make any operator easy to master the operation method.
Easily upgrade.
GP/ST series supports GP series of all models of the screen data, including the first generation of the GP10 series.
GP product family to maintain the size of the opening of the panel compatibility, to facilitate easy replacement.
Rich sample images can reduce programming time.
Pro-face provides a large number of sample images and 3D parts,
So you can easily create a beautiful and intuitive picture, in order to save editing time. Data transmission using USB memory.
In the production site using USB memory can be easily transferred to the production line change and change the screen data.
Safety control function can minimize the problem of production site
Password management functions can be based on each operator or administrator password to enter the set level can be operated by the screen,
According to the function of the operator to set the password to enter the level.
In order to strengthen the management, the operator must enter the ID and the password to operate the equipment.
Error visualization.
The controller is directly connected to the GP, and the key error information of the controller can be displayed on the GP by using the sample unit.
No need to open the control panel, through the PLC to monitor the GP program.
Through the data through the GP function, you can easily debug the ladder program and adjust the data due to changes in the production line by GP easily.
Use USB memory or CF card backup monthly and daily
Recording function using USB memory or CF card can easily improve the efficiency of daily and monthly.
The use of CSV data conversion function can be modified on the PLC GP settings.
Simulated running status on PC.
Use PC simulation function, do not need to transfer the picture to GP,
You can check all the functions of GP on the PC - including the screen operation, D script, logical script.
Remote operation and monitoring in the Office
In the office or other remote side can monitor the production site of the GP screen.
Without picture editing or programming, you can achieve real-time management and monitoring, and now, you can also provide more efficient remote maintenance control.
GP3000-EXDM01 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=GP3000-EXDM01&select=5
