GLC2300 is not availableCOM1 interface with the cable (RS-232C), used to connect directly to the SYSMAC connection module (or other host)5.7 inches, for the protection of the man-machine interface from oil and chemical pollution (5 / set).Connector for connecting DC power cord. (linear, 5 / set)Screen size: 10.4 inches.
Display type: TFT color LCD.
Display color: 256 color (no flash) /64 color (3 speed flicker) GP070-MDCB11
Backlight: CCFL (service life: more than 50000 hours, 24 hours of continuous work).
Resolution: 640 x 480 pixels.
Brightness control: 4 level adjustment can be carried out by touch panel.
Voltage: AC220V.
Internal memory: FLASH EPROM 4MB.
Backup memory: 256KB SRAM.
Interface: Ethernet, CF card. Engineering documents created by the LT interface to download images and logic programming software through the USB interface.Input voltage: DC24V.
Screen size: 10.4 inches.
Display type (resolution):65536 color TFT display LCD (VGA 640 x 480 pixels).
Touch panel type: analog resistance.
Memory: 32MB (internal memory), SRAM320KB (backup memory), SRAM64KB (variable area).
Ethernet interface: 1.
Serial port: RS-232C * 1, RS-422/485 * 1.
SD card slot (max 32GB):1.
USB interface: Type-A x (2) USB 1, Mini-B USB (2) x 1.
Replaceable battery: yes.
Alarm analysis function block: yes.
Panel opening size:
Wide 259 x high 201mm (+1/0mm)
Panel thickness: 1.6-5mm, chamfer radius is less than R3.
Back mounted model: there.
Enhance the display effect.
Meet a number of standards to support a wide range of applications
The coating components are widely used in various working environments, and are in line with the international standards.
Remote data acquisition and management.
Human machine interface, which is installed on the production machine,
With EX Microsoft software combined with Office Pro-Server and SQL and other standard PC software,
Can be simple and economical to establish a set of data management system, and effectively improve the quality of production and efficiency. The Video-Mix module (262000 color video input, 4 channel x, DVI input DVI output x 1 channel, 1 channel x, VGA/SVGA/XGA) *1
GP070-MDCB11 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=GP070-MDCB11&select=5
