Portable GP2000H series models accessories, RS-422 single head cable (10 m).256MB, for the implementation of the picture save, log and data backup and other data management operations, such as compression flash memory card.Screen protection cover (1 pieces) for protecting screen against pollution of man-machine interfaceWhen the man-machine interface is installed to the fixed panel to provide dust proof and moisture proof function GLC100-DIOCN01 (1)Display type: TFT color LCD.
Screen size: 7 inch widescreen.
Resolution: 800 x 480 pixels (WVGA).
Effective display area: H85.92mm * W154.08mm.
Display color: 65536 color.
Backlight: LED.
Brightness adjustment: 8 level adjustment can be carried out by touch panel.
Backlight lamp life: 20000 hours or more (in a 25 C environment, continuous work - brightness decreased to 50% of the original).
Language: Chinese (simplified).
Character size: 8 x 8 pixels, 8 x 16 pixels, 16 x 16 pixels and 32 x 32 pixels.
Font size: 2, 4,, 8, 1,, 2,,, 1, 8, and 4 times.
Interface: x1 RS-232C, x1 RS-422/485, Type-A x1 USB, Mini-B x1 USB (for the project file upload / download).
Input voltage: DC24V.
Using 65536 color 3D simulation components, you can create a beautiful appearance of the operation of the screen.
Due to the use of a widescreen display, so in a picture can also place a keyboard.
Variety of switches and lights and other basic functions can be used in 65536 colors.The man-machine interface directly connected MITSUBISHI electric PLC FX series CPU programming port.Controller DIO (PNP model):6 point type NPN input, 2 point NPN type output, connector: 12 pin.
Specification: DC24/C (control) level models.
Display type: STN pseudo color LCD.
Display size: 10.4 inches.
Resolution: 640 x 480 pixels (VGA).
Display color: 4096 color.
Backlight: cold cathode lamp (replaceable).
Brightness adjustment: 8 level adjustment can be carried out by touch panel.
Touch panel type: resistance type (analog).
Easily upgrade.
GP/ST series supports GP series of all models of the screen data, including the first generation of the GP10 series.
GP product family to maintain the size of the opening of the panel compatibility, to facilitate easy replacement.
Can improve the efficiency of the 5 functions.
Using EX GP-Pro can easily create a clear picture and save the creation time.
Screen and logic programming software EX GP-Pro interface is very friendly,
The drag and drop feature makes the software interface easy to operate.
EX GP-Pro powerful features, such as 3D simulation components, image fonts and simulation functions,
Even beginners can easily and quickly grasp how to create a picture.
Simulated running status on PC.
Use PC simulation function, do not need to transfer the picture to GP,
You can check all the functions of GP on the PC - including the screen operation, D script, logical script.
Record machine status to diagnose error causes.
GP3000 series of M (Multimedia) level models of the event recording function can be recorded in the operation of the device,
This will help save and analyze the error log.
Rich sample images can reduce programming time.
Pro-face provides a large number of sample images and 3D parts,
So you can easily create a beautiful and intuitive picture, in order to save editing time.
GLC100-DIOCN01 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=GLC100-DIOCN01&select=5
